Add robust and secure battery disconnection with the DC Disconnector range from MEANRAY. They are well known for their attention to detail in ensuring maximum user safety.
Maximum DC current = 200A
DC voltage rating: 440V
Overall width: 106mm System size: 195mm
Terminals: M8 lugs with cable area from 25-95mm2
The disconnector needs two fuses at the appropriate rating to be added. Size these based on the maximum battery current with a safety factor applied.
