Description
Pylon US3000C 3.5kWh Li-Ion Solar Battery (excl. brackets)
Part No: PYLON-US3000C
- Weight: 34 kg
- Battery Type: Lithium Ion
- Nominal Energy: 3552Wh
- Depth of discharge: 95.00 %
- Voltage:48 V
- Continuous Discharge Rate: 1776 W
- Maximum Discharge Rate: 3552 W
- Surge Discharge Rate: 4320 W
- Maximum Charge Rate: 3552 W
- Cycle life of 6000 cycles
- Up to 16 units can be stacked in parallel
You can now register the Pylon US3000C for an additional 3 years of manufacturer warranty for free. Go to http://www.pylontech.com.cn/service/support and complete the information in the ‘sign up battery’ page.
Important
Please check battery communication and settings, before connecting grid or PV. A charge voltage over 53.2V will damage the battery.
Voltronic Settings
PDF for Voltronic
Voltronic Inverter Setup SOP updated 0820
Item No. Setting Value
Program 02 Set to N*25A, N=battery amount
Program 05 Set to USE
Program 12 Set to 48V
Program 13 Set to 51V
Program 26 Set to 53.2V
Program 29 Set to 47.5V
DIP switch has been deployed reversely. ON is down, OFF is UP. If DIP switches need to be 1000 then set it to 1110. MAX DISCHARGE AND CHARGE RATE IS ONLY APPLICABLE FOR +- 60 SECONDS
