Felicity IVGM8KLP1G1
| Number of MPPTs | 2 |
|---|---|
| Rated backup output | 8 kW |
| Inverter type | Single-phase hybrid; low-voltage battery |
| Battery voltage range | 40–60 V |
| Maximum battery charge / discharge current | 190 A |
| Recommended PV power | 12 kW |
| Maximum PV voltage | 500 V |
| MPPT voltage range | 120–425 V |
| Maximum PV input current | 26 A + 26 A |
| MPPT trackers / PV inputs | 2 / 4 |
| Maximum efficiency | 97.6% |
| Transfer time | Less than 10 ms |
| Protection rating | IP65 |
| Monitoring | Wi-Fi; Fsolar Smart Cloud |
| Display | 3.5-inch LCD touchscreen |
| Generator port | Generator input, smart load output or microinverter access |
Felicity manufacturer specifications
Product Nr: IVGM8KLP1G1
